Auto metal sheet feeder for power press coil feeder nc servo feeder machine
Auto metal sheet feeder for power press coil feeder nc servo feeder machine
| Categories | Compact Servo Roller Feeder |
|---|---|
| Album | View larger image |
| Brand | HongEr |
| Model | GLK4 |
| Decoiler | Hydraulic Expansion, Motorized, Automatic |
| Straightener | Gear drive, servo motor |
| Servo Feeder | Yaskawa Driver and Yaskawa Motor |
| Oiling Machine | To lubricate and cool down the coil sheet, prolongs the lifespan of dies |
| Shearer | To cut off coil threads |
| Coil Weight | Maximum 15 tons |
| Coil Width | 1600 mm |
| Coil Thickness | 0.6-6.0 mm thick |
| Straightener | upper 4 / lower 3 |
| Warranty | 1 year |
| FOB port | Shenzhen |
| Terms of Payment | L/C, T/T |
| Update Time | 2019-12-09 |
Detail Information
Auto metal sheet feeder for power press coil feeder nc servo feeder machine
3in1 coil feeder Detail Features:
GLK4-800 3in1 decoil straightener feeder machine is customized with safety fence for automotive parts stamping.
Specially designed back pressure roller set, suitable for punching, unwinding and feeding of coils with material thickness of 0.6mm~6.0mm and width of 70mm~1600mm.g
Decoiler
Coil Car
Bearing surface with roller shaft, support to input the material.
Press arm
Coil well-knit, no disperse
Straightner part
GCr15 steel straightener rolls
Specification
Model |
GLK4-400 |
GLK4-600 |
GLK4-800 |
Coil Width(mm) |
400 | 600 | 800 |
Coil Thickness(mm) |
0.6-600 |
||
Max.Coil Weight(kg) |
5000 |
5000 |
7000 |
Max.Coil O.D.(mm) | 1400 | ||
Max.Coil I.D.(mm) | 508 | ||
Max.Feeding Length(mm) | 500 | ||
Max. Speed(m/min) | 16-24 | ||
Straightener Roller(pcs) | Upper4/ Down3 | ||
Feeding Roller (group) | 1 | ||
Servo Motor(kw) | 5.5 | 7.5 | 7.5 |
Uncoiler expansion | Hydraulic | ||
Uncoiler Motor(kw) | 2.2 | 2.2 | 3.7 |
Power Voltage(V) | 220V 60HZ/ 380V 60HZ | ||
Air pressure(Mpa) | 0.49 | ||
Application
layout-products
GLK4-600H high yield strength decoiler straightener and feeder machine is suitable for 600mm width metal coil sheet with high tensile. This 3 in 1 unit feeder machine with automatic system can be equipped with mechanical press machine for automobile stamping in Tier 1 manufacturers.
Our Customer
UnCoil feeder machine in UK
3 IN 1 Combo coil feeder machine for automotive stamping line equipped with mechanical press machine
